Description
Technical Specifications:
- Operating Frequency: 13.56 MHz
- Chip Type: NXP MIFARE Classic 1K
- User Memory: 1024 Bytes (16 sectors of 4 blocks)
- UID size: 4 Bytes
- Range: Up to 10 cm (depending on antenna geometry)
- Data Transfer Rate: up to 106 kbps
- Communication Protocol: ISO/IEC 14443-A
- Dimensions: 85.6mm x 54mm x 0.8mm (ISO standard card size)
- Material: PVC
- Factory default A/B key: FF FF FF FF FF FF
Features:
- Durable and waterproof PVC material
- Small and portable design
- Compatible with various NFC-enabled devices including ACR122U reader.
- Uses CRYPTO1 encryption to protect data transmission and access control.
- Easy to use and program
- Cards can be printed by printers using dye-sublimation or thermal transfer printing. Such as Zebra, Epson, and Canon.
Applications:
The MIFARE Classic 1K card, known for its ample memory capacity, robust security features, broad compatibility, cost-effectiveness, and durability, is widely applied in access control, public transportation ticketing, loyalty programs, payments, and identification badges.
Specifications
| Weight | 0.007 kg |
|---|---|
| Application | Bank, Enterprises, Festival, Gift Card, Hotel Card, Identification, Parking |
| Chip | |
| Communication Interface | HF RFID |
| Frequency | |
| Material | PVC |
| Protocol | |
| Size | CR80 85.6x54mm(3.37"x2.13") |
| Package | 1 Piece, 10 Pieces, 200 Pieces, 600 Pieces, 1,000 Pieces |
